Flatpack S 24V/1000W HE

Applications in these markets demand state of the art, reliable and safe DC power systems. Flatpack S delivers an industry leading power density in its segment, many safety functions, wide operating temperature range and superb reliability in its small 217mm deep housing.


Product Introduction

Features & Benefits

Compact and reliable rectifier for rail and power utilities applications
Used in the 3U rack with Smartpack S controller, the Flatpack S rectifiers cover 2 to 8kW applications using a minimum of space, less than 18 liters, and low heat dissipation.

• Small
• Short
• Power dense, 26 W/inch3
• High efficiency
• OR-ing protection on output
• Hot pluggable
• Voltage keying

Specifications

Input
Voltage AC (operating range)	85 - 305 VAC
Voltage DC (operating range)	85 - 300 VDC
DC Output
Max Power	1000 W
Voltage (adjustable range)	21,5 - 28 VDC
Current (maximum)	28 ADC
Max voltage	28 VDC
Other
Cooling	Single fan
Efficiency	92,5%
Operating temperature	-40 - 85 °C
Dimensions
Dimensions WxHxD (mm)	72 x 41,5 x 217 mm
Dimensions WxHxD (inch)	2,83 x 1,63 x 8,54 "
Weight	0,85 kg
Design Standards
Ingress Protection (IP)	20

Download

Fact sheet / 331 KB
